Miyano Machinery was founded in 1929 in Kameido, Tokyo. Making precision industrial files, the company designed its first automatic lathe in 1948. As demand rose for this lathe, it became more widely commercially available.

Since then, Miyano has been continually pushing the industry forward:

  • 1963 – Central control of cam axis
  • 1971 – 4-Axis auto lathe
  • 1975 – MTP-3BC
  • 1985 – 5-axis ANC-35/45
  • 1997 – Japan's Prize for New Machine Developed by Small/Medium Enterprises

Miyano has been a pioneer in the development of automatic lathes, continually achieving advances in productivity with an unrelenting dedication to providing the highest level of precision. Elements of all Miyano machines reflect this dedication.


Miyano Quick Reference Guide

42MM / 1.653" Thru-Spindle Bar-Fed CNC Lathes


ANX-42SYY Linear Ways Lathe with Low Frequency Vibration
  • Six cutting axes (X1, Y1, X2, Y2, Z1, Z3)
  • Fanuc 32i-B Control
  • 20,000 RPM Main Spindle
  • 20,000 RPM Back Spindle
  • Gang tool max 8,000 RPM
  • 17 Tools Total
  • Live Tools 2 (3 optional)

BNA-42S2
  • 5-Cutting Axes (X, Z, B, C1, C2)
  • Fanuc 0i-TD Control
  • Two Spindles
  • One 8-Live Tool Station Turret w/Half-Indexing (16-Station Capability)
  • 6,000 RPM Main Spindle
  • 5,000 RPM Back Spindle
BNA-42SY5
  • 6-Cutting Axes (X, Z, Y, B, C1, C2)
  • Fanuc 0i-TF+ Control (Automation-Ready)
  • Two Spindles
  • One 12-Live Tool Station Turret with Y-Axis
  • 6,000 RPM Main Spindle
  • 5,000 RPM Main Spindle
BNA-42DHY3
  • 7-Cutting Axes (X1, Z1, Y1, X2, Z2, C1, C2)
  • Fanuc 0i-TD Control
  • Two Spindles
  • Two (8- and 6-Live Station) Turrets
  • 6,000 RPM Main Spindle
  • 5,000 RPM Back Spindle

BNA-42MSY2
  • 7-Cutting Axes (X1, Z1, Y1, X2, Z2, C1, C2)
  • Mitsubishi M70 Control
  • Two Spindles
  • One 8-Live Tool Station Turret w/Half-Indexing (16 Station Capability)
  • 6,000 RPM Main Spindle
  • 5,000 RPM Back Spindle
  • Simultaneous Front-Back Machining Capability
BNA-42GTY w/Gang Tool Slide
  • 10-Cutting Axes (X1, Z1, Y1, X2, Z2, Y2, X3, Z3, C1, C2)
  • Mitsubishi M730VS Control
  • Two Spindles
  • One 8-Live Tool Station Turret w/Half-Indexing & Y-Axis
  • 6,000 RPM Main Spindle
  • 5,000 RPM Back Spindle
  • Simultaneous Front-Back Machining Capability

51MM / 2" Thru-Spindle Bar-Fed CNC Lathes


BNX-51MSY
  • 7-Cutting Axes (X1, Z1, Y1, X2, Z2, C1, C2)
  • Mitsubishi M70V Control
  • Two Spindles
  • One 12-Live Tool Station Turret with Y-Axis
  • 5,000 RPM Main & Back Spindle
  • Simultaneous Front-Back Machining Capability
BNJ-51SY6
  • 7-Cutting Axes (X1, Z1, Y1, X2, Z2, C1, C2)
  • Fanuc 0i-TF Control
  • Two Spindles
  • Two (12- and 8-Live Tool Station) Turrets with Y-Axis
  • 5,000 RPM Main & Back Spindle
  • Simultaneous Front-Back Machining Capability

BNE-51MSY
  • 9-Cutting Axes (X1, Z1, Y1, X2, Z2, X3, Z3, C1, C2)
  • Mitsubishi M730VS Control
  • Two Spindles
  • Two 12-Live Tool Station Turrets (One with Y-Axis)
  • 5,000 RPM Main & Back Spindle
  • Simultaneous Front-Back Machining Capability
BNE-51MYY
  • 9-Cutting Axes (X1, Z1, Y1, X2, Z2, X3, Z3, C1, C2)
  • Mitsubishi M830W Control
  • Two Spindles
  • Two 12-Live Tool Station Turrets with Y-Axis Slides
  • 5,000 RPM Main & Back Spindle
  • Simultaneous Front-Back Machining Capability

65MM / 2.5" Thru-Spindle Bar-Fed CNC Lathes


ABX-64SYY2
  • 9-Cutting Axes (X1, Z1, Y1, X2, Z2, Y2, Zsp, C1, C2)
  • Fanuc 31i-B Control
  • Two Spindles
  • Two (2) 12-Live Tool Station Turrets Both with Y-Axis
  • 40-Nm Live Tools w/6 HP Motor for Heavy Milling
  • 4,000 RPM Main & 5,000 RPM Back Spindle
  • Simultaneous Front-Back Machining Capability
ABX-64THY2 w/Three Turrets
  • 9-Cutting Axes (X1, Z1, Y1, X2, Z2, Y2, X3, Z3, C1, C2)
  • Mitsubishi M830W Control
  • Two Spindles
  • Two 12-Live Tool Station Turrets w/Y-Axis
  • 25-Nm Live Tools w/5 HP Motor for Milling
  • 5,000 RPM Main & Back Spindle
  • Simultaneous Front-Back Machining Capability

BNE-65MYY
  • 9-Cutting Axes (X1, Z1, Y1, X2, Z2, X3, Z3, C1, C2)
  • Mitsubishi M730VS Control
  • Two Spindles
  • Two 12-Live Tool Station Turrets (One with Y-Axis)
  • 5,000 RPM Main & Back Spindle
  • Simultaneous Front-Back Machining Capability

38MM and smaller Bar Capacity:

Click here to see our Marubeni Citizen-cincom CNC Swiss Type Lathe Offerings.



Other models may be available by special order - call your local dealer for more information.
Export License requirements must be confirmed before shipping out of the US.
